Floating Engineered Wood Floor

It's hard to imagine a house being cozy without the warmth of wood flooring. The quickest way to get new wood underfoot is to install a floating floor. Unlike traditional solid-wood strips, a floating floor isn't nailed down. Instead, the planks are either glued or snapped together. The planks go down fast, over virtually any material—concrete, plywood, sheet vinyl, even ceramic tile.

There are several floating floor materials available, but if you want real wood, the best choice is engineered flooring. This sandwich of wood veneer glued to layers of pine or plywood looks like solid wood and is very stable. Although engineered flooring's thin veneer can't be sanded as many times as solid wood can, its thick factory-applied coating is more durable than one applied in your home on solid wood, and it will be ready for furniture in just one day. Read on to see how to install a floating engineered wood floor.

Shown: Chesapeake Hickory Plank in Cherry Spice, from Mannington

Floating Hardwood Floor Overview

Floating Hardwood Floor Parts Diagram Illustration by Gregory Nemec

Engineered flooring goes down over a thin foam sheet, which provides cushioning and sound-dampening. The planks glue together to create a floor that "floats" — moves freely — as a unit. You need to leave a 5/16-inch gap between the flooring and the baseboard or wall around the perimeter of the room to allow the floor enough space to expand.

In most cases, you can install the flooring without removing existing baseboard, concealing the expansion gap with shoe molding (or quarter-round, which is wider). Or, you can remove the baseboard, lay the flooring, and then reinstall the baseboard on top. Regardless of which method you use, nail the molding to the wall, not the flooring, so the floor can move.

Once the prep work is done, decide which direction to lay the flooring. Running the planks parallel with the longest wall usually looks best. Then measure the width of the room (subtract 5/8 inch to account for the expansion gap on both sides) and divide by the width of the flooring you've chosen to calculate how many courses of planks will be needed.

Chances are you'll need to rip, or trim lengthwise, the last course to fit. If your calculation results in a final course that's at least 1 ½ inches wide, then the first course should be a full-width plank. But if the last course is narrower, rip the first course down to ensure the last course will have a pleasing width.

How to Install Floating Floor

1. Trim the door casings

Man Trims Bottom Of Door Casing With Flush-Cut Dovetail Saw Photo by Kolin Smith
  • Use a flush-cut dovetail saw to trim the bottom of the casing at all doorways so that the flooring will slide underneath.
  • Gauge the height of the cut by laying down a piece of foam underlayment and a piece of flooring (upside down so the saw won't scratch the finish).
  • Then hold the saw flat against the plank and carefully make the cut.

2. Install the foam underlayment

Man Installs The Foam Underlayment Photo by Kolin Smith
  • Vacuum the room, then unroll the foam underlayment.
  • Cover the entire room with a single layer, trimming it to fit with a utility knife and butting the seams together.
  • Seal the seams with duct tape.

3. Install the first course

Man Installs First Course Of Floating Floor Planks Photo by Kolin Smith
  • Lay down the first plank with its grooved end in the corner against a spacer block. Also place spacers along the starting wall. As you set the flooring, always keep the tongues facing out and cut ends against a wall.
  • To fill in the pieces in the first course, place a spacer against the wall, and measure from it to the last plank installed.
  • Mark this measurement on a new plank, starting at the grooved end so it will mate with the tongue of the last plank. Cut the plank to length.
  • Apply glue to the end groove of the new piece, and install.
  • Slip a pry bar between the end of the plank and the spacer and lever the joint together. Then push the piece down in place. Remove excess glue with a damp cloth.

4. Install the rest of the flooring

Man Installs Remaining Floating Wood Floor Planks Photo by Kolin Smith
  • Start each course with the piece of flooring left over from the previous cut (cut end to the wall), as long as it is more than 8 inches in length. This will keep the joints staggered. Remember to place spacers against side walls before you put down a plank.
  • Squeeze glue into the groove of the plank in one continuous bead, then slide it up against the previous row. Set a wood block against the outside of the plank, and tap it with a hammer to bring the planks tightly together.
  • Measure from the plank to the end of the row and finish the course as detailed in Step 3. Continue installing planks in this manner, one course at a time. Every four to six courses, use blue painter's tape to keep the joints tight while the glue cures.

5. Measure for the last course

Man Measures The Last Course Of Wood Planks Photo by Kolin Smith
  • When you reach the final course, measure the width needed for the last plank. Again, measure to a spacer placed against the wall, to account for the expansion gap.
  • A plank that runs across a door will have to be notched to fit inside the doorway. To determine its width, measure to the closer edge of the doorstop molding.

6. Rip the plank to width

Man Rips Floating Wood Plank To Width Using Jigsaw To Fit Underneath Casing Photo by Kolin Smith
  • Use a jigsaw to rip the plank to width and to cut the doorway notches, above center. Cut the plank so it fits underneath the casing and reaches the doorstop. Use a fine-tooth wood blade, and cut slowly.

7. Pry in the last course

Man Pries In Last Floating Wood Plank With Pry Bar Photo by Kolin Smith
  • Getting this final course in requires patience and persuasion. Remove the spacers on the last wall for wiggle room, then use a pry bar to pull the piece tight against the previous course. If necessary, slide the plank into place by coaxing it with the block and hammer.
  • Allow glue to cure at least 12 hours before removing the painter's tape and spacers and trimming out the room with molding along the perimeter.

8. Install the finish trim

Man Installs Finish Trim After Floating Floor Is Finished Photo by Kolin Smith
  • Trim the doorstops on either side of the doorway to the height of the transition molding. Then cut a piece of transition to fit between the doorjambs.
  • Set the transition on the subfloor. Overlap the flooring on either side, but leave a 5/16-inch gap against the floating floor. Drill three pilot holes along its center to keep the transition molding from splitting, then fasten it to the subfloor — not the flooring — with 4d finish nails.
  • Now measure the walls for shoe molding. Try to complete each wall with one piece. If necessary, join pieces with a scarf joint.
  • For inside corners, use a coped joint or simply miter the two pieces. Cut miters for outside corners, too.
  • Set the molding in place tightly against the floor. Fasten it to the baseboard — not the flooring — with 4d finish nails.
