Step 7: Make the Cuts for the Feet and Brackets

Photo: Kolin Smith
«»
Position the blank with the waste angle off the table. Clamp a straightedge parallel with the cutline, using a piece of scrap to support one end if necessary (as shown). Set the circular saw's blade depth to 1 inch, and run the shoe along the straightedge to cut the first angle. Use the same setup to cut the other angle, then use the piece to trace cutlines on the remaining seven blanks for the feet and brackets and cut them in the same manner.
Ask TOH users about Decks

Contribute to This Story Below

    Tools List

    • 30-foot tape measure
      Tape measure
    • miter saw
      Miter saw
    • bar clamps
      Long and short bar clamps
    • drill
      Drill/driver
    • 1/8-inch bit with combination countersink
      -inch combination countersink bit
    • straight edge
      Straightedge
    • circular saw
      Circular saw
    • router
      Router with a ¾-inch straight bit
    • multi-bit screwdriver
      Screwdriver
    • 1/8-inch twist bit
      -inch twist bit
    • spade bit
      1-inch Forstner (or spade) bit
    • adjustable wrench
      two adjustable wrenches

    Shopping List

    1×4 cedar Get eleven 10-footers.

    Igloo Ice Blue MaxCold 50 cooler with threaded drain plug. Go to igloo-store.com

    1½-, 1¼-, and 2-inch deck screws

    -inch brass or stainless-steel screws for the lid slats

    ½-inch brass spigot

    ½-by-3-inch brass nipple

    ½-inch brass double female connector

    29-inch brass or stainless-steel continuous hinge

    Brass or stainless-steel gate handle

    24-inch brass or stainless-steel sash chain

    Wall-mount bottle opener

    Teflon tape

    Double-sided foam tape
