Step 9: Assemble the Legs

rolling outdoor grill table put together legs
Photo: Kolin Smith
«»
Clamp the two boards for the stationary leg around a scrap of the same material, then clamp a foot to the assembly. Countersink four holes, as shown, and attach the foot with 1¼-inch deck screws. Attach the paired foot on the leg's other side, and opposing brackets at the other end for the tabletop. For the wheeled leg, attach only the foot pieces.
Ask TOH users about Outdoor Kitchens

Contribute to This Story Below

    Tools List

    • miter saw
      Miter saw
    • bar clamps
      Bar clamps
    • straightedge guide
      Straightedge
    • router
      Router with ¾-inch straight bit
    • combination square
      Combination square
    • Doweling Jig
      -inch doweling jig. Go to rockler.com.
    • drill
      Drill/driver
    • 3/8-inch drill bit
      -inch drill bit
    • hacksaw
      Hacksaw
    • 1/16-inch drill bit with combination countersink
      1/16-inch drill bit with a combination countersink
    • bevel square
      Bevel gauge
    • circular saw
      Circular saw
    • 1/2-inch drill bit
      ½-inch drill bit

    Shopping List

    1. 1x4 cedar. Get seven 10-footers.

    2. -inch by-2-inch spiral-cut wood dowels

    3. -inch brass wood screws to attach the tabletop slats

    4. 1¼-inch deck screws

    5. -inch aluminum rod Get 34 inches.

    6. ½-inch threaded galvanized rod for the axle (36 inches, 13 threads per inch)

    7. ½-inch galvanized flat washers

    8. ½-inch locknuts (13 threads per inch)

    9. 8-inch-by-1¾-inch lawn-mower wheels

    10. Wood glue
