Step 15: Fasten the Backrest

measuring the distance between the back legs to accommodate the back rest for a Westport chair
Photo: Wendell T. Webber
«»
Stand the completed backrest between the back legs, and hold it in position with a long bar clamp. Check that the seat, backrest, and back legs fit together snugly. Once you're sure they do, drill pilot holes and use screws to attach the seat to the top edges of the back legs and attach the back legs to the lower edges of the backrest.

Tip: Before fastening the horizontal front rail to the front-leg notches, set the seat between the legs to act as a perfect-size spacer.
Ask TOH users about Furniture

Contribute to This Story Below

    Tools List

    • miter saw
      Sliding compound miter saw to crosscut the boards to length
    • adjustable clamp
      Clamps to hold the parts together during assembly
    • circular saw
      Circular saw to cut the parts to width
    • framing square
      Framing square and combination square for marking cutlines
    • jigsaw
      Jigsaw to cut notches and curves
    • drill
      Drill/driver
    • hand plane
      Hand plane to straighten board edges
    • sandpaper
      120-grit sandpaper
    • sanding block
      Sanding block
    • pencil compass
      Compass
    • torpedo level
      Torpedo level
    • 3-inch wide paint brush
      3-inch paintbrush to apply teak oil

    Shopping List

    ½ x 10 cedar boards.
    Get four 8-foot lengths

    1 -inch stainless-steel trim-head screws

    Teak oil to finish the chair
