Step 3: Attach the Hinges

installing hinges on the bifold doors with a drill/driver
Photo: Ryan Benyi
«»
Hold two panels back-to-back and on edge, as shown. Mark the edges of the doors where the hinges will be installed so that the knuckles sit 4 inches in from the top and bottom. Drill pilot holes and screw the hinges in place. Repeat on the second door. Once the hinges are installed, you should have two bifold doors with the knuckles on the TV side of the doors.
Next

Related Content

Ask TOH users about Cabinets & Shelving
Discuss

Contribute to This Story Below

Add Comment

    More in Interior

    Tools List

    Close
    • circular saw
      Circular saw
    • combination square
      Combination square
    • speed square
      Speed Square
    • miter saw
      Miter saw
    • drill
      Drill/driver
    • Countersink bit
      Countersink bit

    Shopping List

    Close
    1. Bifold door Select a solid-wood bifold door. To determine the width you'll need, add about 4 inches to the width of your monitor and divide by 2. You'll need to round up to the nearest stock door size.

    2. 1x stock Choose boards for the sides wide enough to span from the wall just past the face of the TV, as it protrudes from the wall. For the top and bottom, choose boards at least 2 inches wider than the side boards, to account for the thickness of the doors and the beveled overhang. 3. 1x4s to make the cleat and crosspiece. Get two 6-foot boards.

    4. Bifold door hinges to join the halves of each door once you cut it down. Reuse the three that come with your doors and get one more.

    5. Flush-door H hinges to attach the doors to the frame. Get four.

    6. 1½-inch screws7. Magnet catches made for cabinets. Get two.
