Step 11: Position the Leg Assembly

Tom Silva positions the leg assembly to the underside of the table top for a trestle table
Photo: Allison Dinner
«»
Flip the leg assembly over and place it on the underside of the tabletop. Make sure the leg plates lie flat, without wobbling or rocking. The legs should sit an equal distance from the short and long ends of the table.
Next

Related Content

Ask TOH users about Furniture
Discuss

Contribute to This Story Below

Add Comment

    More in Interior

    Tools List

    Close
    • circular saw
      Circular saw
    • miter saw
      Miter saw
    • drill
      Drill/driver fitted with a ⅝-inch paddle bit
    • pneumatic finish nailer
      Pneumatic nail gun

    Shopping List

    Close
    1. Newel posts Get two for the legs.

    2. ¾-inch birch-veneer plywood Get a 4x8 sheet for the tabletop and leg plates.

    3. 10 ½-inch corbel Get four for the feet.

    4. Handrail Get a 6-foot length for the stretcher.

    5. ⅝-inch dowel Get a minimum of two inches to plug the fastener holes for the stretcher.

    6. 1x2 Get an 8-foot length to make the cleats for the underside of the tabletop.

    7. 1x4 Get three 6-foot lengths to make the apron.

    8. 2x4 Get a 6-foot length to make the stringers. 9. ¾-inch quarter-round trim Get three 8-foot lengths to trim the edges of the tabletop.

    10. 6-inch lag screws Get two to attach the stretcher to the legs.

    11. 8-inch lag screws Get eight to attach the feet to the legs.

    12. 3-inch deck screws

    13. 1¼-inch deck screws

    14. 2-inch finishing nails

    15. Wood glue

    16. 120-grit sandpaper

    17. Satin latex paint

    18. Waterborne polyurethane finish
