Step 7: Attach the Cleats

Tom Silva attaches cleats to the underside of the table top for a trestle table with a drill/driver
Photo: Allison Dinner
«»
Draw a guide line on the underside of the tabletop that's 3 inches from each edge. Secure 1x2 cleats on the flat along the inside edge of the line, using 1¼-inch deck screws. Space the cleats to leave enough room to install two 2x4 stringers between the spots where the leg plates will be attached.
Next

Related Content

Ask TOH users about Furniture
Discuss

Contribute to This Story Below

Add Comment

    More in Interior

    Tools List

    Close
    • circular saw
      Circular saw
    • miter saw
      Miter saw
    • drill
      Drill/driver fitted with a ⅝-inch paddle bit
    • pneumatic finish nailer
      Pneumatic nail gun

    Shopping List

    Close
    1. Newel posts Get two for the legs.

    2. ¾-inch birch-veneer plywood Get a 4x8 sheet for the tabletop and leg plates.

    3. 10 ½-inch corbel Get four for the feet.

    4. Handrail Get a 6-foot length for the stretcher.

    5. ⅝-inch dowel Get a minimum of two inches to plug the fastener holes for the stretcher.

    6. 1x2 Get an 8-foot length to make the cleats for the underside of the tabletop.

    7. 1x4 Get three 6-foot lengths to make the apron.

    8. 2x4 Get a 6-foot length to make the stringers. 9. ¾-inch quarter-round trim Get three 8-foot lengths to trim the edges of the tabletop.

    10. 6-inch lag screws Get two to attach the stretcher to the legs.

    11. 8-inch lag screws Get eight to attach the feet to the legs.

    12. 3-inch deck screws

    13. 1¼-inch deck screws

    14. 2-inch finishing nails

    15. Wood glue

    16. 120-grit sandpaper

    17. Satin latex paint

    18. Waterborne polyurethane finish
