marking a cut line on board with a pencil
Photo: Matthew Benson

Step 6: Mark and Cut the Short Battens

Cut two more battens at the same angle. Since they taper down to a single board in front, you can mark each batten's height with the width of a board, as shown. Cut both battens.
Ask TOH users about Outdoor Structures

Contribute to This Story Below

    More in Landscaping

    Tools List

    • miter saw
      miter saw
    • jigsaw
    • drill
    • straightedge guide
    • hand clamps
    • caulk gun
      caulk gun
    • metal garden rake
      garden rake
    • garden spade
      garden spade

    Shopping List

    1. 5/4x6 decking by Cambia. Get at least three 8-foot boards.

    2. salvaged window sash 3. pavers Get enough to set beneath each side of the frame.

    4. construction adhesive

    5. 1-inch deck screws

    6. 2½-inch deck screws

    7. brass sash pull

    8. 4-inch galvanized strap hinges Get two to attach the window to the frame.

    9. 4-inch removable-pin hinges Get one for the inside of each corner to make the frame collapsible.

    10. ½-inch dowel Get at least 6 feet to make venting poles of various lengths.
