How to Build a Dog Ramp

By: Jennifer Stimpson, This Old House online

Shopping List

Supplies You Will Need

1. 1x12 laminated shelving board Get one 6-foot board.

2. 1x5 Get two 8-foot boards.

3. 1 5/8-inch trim head screws

4. 3/8-inch 2½-inch bolts to attach the legs to the box. Get two.

5. 3/8-inch washers Get ten.

6. 3/8 inch locking nuts Get two.

7. Wood glue

8. Wood filler

9. Piano hinge Get one that's 30 inches long.

10. Folding door hinge

11. Toy box lid supports

12. Drawer pull

13. Nonskid rubber strips or pads

14. Round skid feet

15. Latex primer

16. Latex semi-gloss paint

17. Contact cement

18. Non-skid/sisal rug

19. Coffee can

Close
Tools List
Tools You Will Need
- Jigsaw
- Speed square
- Drill/driver fitted with a 3/8-inch drill bit
- Paint brush
- Putty knife
- Screwdriver
- Adjustable wrench
Close

man attaching a non slip rug to the lid of the pet ramp

Photo: Wendell T. Webber

Introduction
Overview
Steps:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11

10. Mount a Non-Slip Rug on the Lid

Cut a nonslip rug, like the sisal shown here, to the size of the lid. Roll contact cement onto the top of the lid and the underside the sisal rug in a well-ventilated area. Allow the contact cement to dry to the touch. Place scrap strips of wood on top of the lid to keep the surfaces from making contact and instantly bonding before the rug is perfectly positioned.

Place the end of the rug flush with the end of the lid. Slowly remove the scraps, allowing the rug to bond to the lid, making sure the edges stay flush with the edges of the lid. Work your way from one end of the lid to the other until the rug is secure.
