Step 4: Transfer the Template Shape

transfer the template shape
Photo: William P. Fuller
«»
Once the template is securely glued together at every intersection, turn it over and transfer your marks to the back. Then lay it facedown on the back of the solid surface. Trace around its outside edge, and inside the cutouts you indicated.

TIP: When marking the panel, make Xs through the areas meant to be cut away.
Next

Related Content

Ask TOH users about Backsplashes
Discuss

Contribute to This Story Below

Add Comment

    More in Kitchen

    Tools List

    Close
    • hot glue gun
      Hot Glue Gun

    • four-foot level
      4-Foot Level

    • circular saw
      Circlar Saw

    • jigsaw
      Jigsaw fitted with metal cutting blade

    • drill
      Drill/Driver fitted with with 3/8-inch masonry drill bit

    • utility knife
      Utility Knife

    • caulk gun
      Caulk Gun

    • hammer with nailset
      Hammer and Nail Set

    Shopping List

    Close
    1. Solid-Surface Wall Paneling. Look for 1/4-inch-thick material, available in large sheets at home centers or through distributors. Get the widest sheets you can find to minimize joints.

    2. All Purpose Kitchen Cleaner, such as Formula 409 or Fantastik, to clean grease off the wall and prepare it for adhesive.

    3. 1/4-Inch Plywood, aka luaun, to make the template.

    4. Painter's Tape

    5. Construction Adhesive to adhere the backsplash to the wall.

    6. Tack Cloth

    7. Heavy-Duty Double-Stick Tape to hold the panel in place while the adhesive sets.

    8. All-Purpose Caulk to seal seams between panels and against cabinets. Get a color to match the solid-surface material, or else use clear.

    9. 1x3 Pine Lumber to cap any exposed edges.

    10. 1 1/2-Inch Finish Nails

    11. Paint to coat any molding detail to match the backsplash material.
