Step 2: Line up the parts

drill pilot holes
Photo: Wendell T. Webber
«»
Drill four evenly spaced pilot holes into the back crosspiece, ¾ inch in from the ends. Then drill four evenly spaced pilot holes into the front grille piece, 2¼ inches in from the ends.

Lay down each side piece, with the insides facing up, and attach the corner supports. The front corner supports should be flush with the front edge of the side; the back corner support is inset 1½ inches from the bottom edge of the tail fins.

From the front end, measure 14¼ inches along each side. Drill four pilot holes down the face. This is where the center crosspiece will go.
Ask TOH users about Outdoor Structures

Contribute to This Story Below

    More in Landscaping

    Tools List

    • 30-foot tape measure
      Tape measure
    • speed square
      Triangular layout square
    • jigsaw
      Jigsaw with coarse, wood-cutting blade
    • bar clamps
      4-foot bar clamps
    • drill
      Drill/driver fitted with 1/8-inch bit
    • safety glasses
      Safety glasses
    • paintbrush
      Paintbrushes
    • square shovel
      Shovel
    • Thatch-rake
      Steel rake
    • four-foot level
      4-foot level
    • utility scissors
      Utility scissors
    • staple gun
      Staple gun
    • pencil compass
      Compass

    Shopping List

    1. Four 8-foot pressure-treated 2x12s

    2. Two 8-foot pressure-treated ½x6 decking boards

    3. One 6-foot pressure-treated 2x4

    4. 2 square feet of ½-inch pressure-treated plywood

    5. Steering-wheel cover

    6. 3-inch deck screws

    7. ¼x1-inch zinc fender washer8. Two drawer handles

    9. Two sets of 2½-inch stainless-steel butt hinges

    10. Latex exterior stain

    11. Latex exterior paint

    12. Landscape fabric

    13. 20 bags of play sand
