Step 7: Hang the door and attach the hardware

Hanging the door and attaching the hardware.
Photo: Kolin Smith
«»
Once all the holes and mortises are finished, prime and paint or stain and finish the door. Make sure to cover all six sides with finish so it's completely sealed and won't swell in high humidity.

Position one half of a hinge (with the inner knuckles) in its mortise on the door. Use a centering punch to make starting divots for the screws. Screw the hinge leaf to the door. Repeat on the other two hinges. Screw the other halves of the hinges to the doorjamb.

Hang the door, slotting the hinges together and slipping in the pins.

Install the lockset. Attach the backplates (or escutcheons) and door-knobs. Don't screw the knobs onto the spindle too tightly or you won't be able to turn them. Screw the new strike plate to the jamb.
Ask TOH users about Doors

Contribute to This Story Below

    Tools List

    • folding ruler
      Tape measure and folding ruler
    • circular saw
      Circular saw
    • bench plane
      Bench plane
    • combination square
      Combination square
    • wooden mallet
      Mallet
    • drill
      Drill/driver with auger bits
    • centering punch
      Centering punch
    • ratcheting screwdriver
      Screwdrivers
    • hand clamps
      Clamps

    Shopping List

    1. DOOR

    Measure the width of your opening, jamb to jamb, in three places (top, middle,bottom) and the height, threshold to jamb, in three places. Note the largest of each and use these as a guide to buy the door.



    2. KNOB SET

    A set for a cylinder lock should include two knobs, a spindle, and two round escutcheon plates. For a mortise lock with a bolt, two escutcheons or a long backplate with a keyhole may be required.



    3. LOCKSET

    Choose between a cylinder lock (a tube-shaped ;acthset with a lock on the knob) or a mortise lock (a rectangular set with a bolt and a skelton key). You can reuse an old lock, but a new mortise lockset might be worth the cost (less than $20) just for the mortise-cutting template that comes with it. Before buying a mortise lock, make sure the distance from the spindle hole to the keyhole matches the one on the backplate you choose, and that the lock body isn't too thick to fit your door.



    4. HINGES

    You will likely need three to hanadle the weight of a solid-wood door or solid-core door. Many doors come with instructions that indicate the size and number needed.



    5. LOCK INSTALLATION KIT

    If necessary, for drilling for a cylinder lock. Tool companies make these kits, which come with two different hole saws that attach to a drill, along with a jig to guide where the holes go. Some kits also include a drill-mounted router bit and jig for carving out shallow mortises for the lock's faceplate and the strike plate.



    6. WOOD SHIMS

    To hold the door in its opening as you check the fit and mark for hinges.
