Step 7: 7. Mark cut lines on the boards

Marking cut lines with a pencil.
Photo: Kolin Smith
«»
After marking the beadboard at the sides of the opening, mark the distance between the last board and the edge of the hole onto the face of the board. Take the board down and use a square to extend your marks to meet each other. Notch the board with a jigsaw. If the opening is big enough, install cut boards butted against the sides of the hole, then finish with another notched board.

For a circular opening, dry fit each piece individually and reach into the hole with a marker and trace the shape of the opening on the back of the board.
Next

Related Content

Ask TOH users about Porch
Discuss

Contribute to This Story Below

Add Comment

    More in House Exterior

    Tools List

    Close
    • 16-foot tape measure
      Tape measure
    • miter saw
      Miter saw
    • jigsaw
      Jigsaw
    • pneumatic finish nailer
      Pneumatic finish nailer,
      rents for $35 a day, with compressor
    • combination square
      Combination square
    • pneumatic brad nailer
      Pneumatic brad nailer,
      rents for $22 a day, without compressor

    Shopping List

    Close
    1. PREPRIMED BEADBOARD

    Beadboard comes in different-width tongue-and-groove strips that fit together to look like one continuous bead-and-board panel. It also comes in lengths anywhere from 8 to 16 feet. Pick the length that’s just longer than your porch is deep so one board can run the whole depth of the ceiling without seams.



    2. LATTICE

    For covering the 1/4-inch expansion gap around the perimeter of the beadboard. Lattice is flat 11/2-by-1/2-inch stock, usually made from treated pine. For the amount you'll needmeasure the perimeter of the ceiling, then add 10 percent.



    3. 2-INCH FINISH NAILS

    For nailing up the beadboard. Make sure you get nails made to fit the gun you rent. About 200 will suffice for 100 square feet of 1x6 beadboard, which means two strips is more than enough.



    4. 1-INCH BRADS

    For attaching the lattice. One strip of brads should be enough.
